BG-80D Automatic pharmaceutical film coating machine for tablet
Introduction
The product is an ideal film coating machine in current pharmaceutical industry at home. It can be applied in many fields like pharmacy, food, biological products, etc.. The machine is particularly applied to coat tablets, pills, and candies with all kinds of organic or water-soluble film. As a film coating machine, it is widely applied in pharmacy and food industry.
Features
1.PLC and temperature module controlling system with the touch screen produced by Siemens Germany are applied to provide picture displaying, convenient operation, energy-efficiency, cleanliness and safety, and convenient cleaning, which meets the standard of GMP.
2.Components, which drugs are exposed to, such as high efficiency film coating mainframe, high efficiency hot air filter, dust removal fan and spray device, are all made of imported stainless steel of good quality.
3. The procedures are all controlled by PLC touch screen, automatically or manually.
4.Coating is processed in totally closed environment to prevent dust and slurry from spilling. The surface of box is polished and its light pollution is eliminated.
5.The driver system applies explosion-proof decelerating motor and chain-wheel transmission device, which can make frequency conversion continuously variable.
6.High efficiency hot air filter can directly capture air from outside, heat the air after primary, intermediated and high efficiency filter, and then provide the air for the mainframe. The air can meet the standard of 100,000 class cleanliness. Dust removal fan can exhaust air to the outside to avoid the influence on central air-conditioning and to save energy.
7. Spray gun is the WA-101 spray gun imported from Japan of good atomization, non-clogging nozzle, adjustable spray volume and angle, and simple structure which is convenient to clean.
Technical Parameters
|
Items |
Parameters |
|
|
Model |
BG-80D |
|
|
Production quantity |
80Kg every time |
|
|
Speed range of film coating roller |
3-24 r/min |
|
|
Diameter of material inlet |
380mm |
|
|
Diameter of film coating roller |
930mm |
|
|
Diameter of roller mesh |
3mm |
|
|
Motor power of mainframe |
1.5KW (The mainframe is totally closed) |
|
|
Air source (supplied by the user) |
0.8 m3/min Pressure: ≥0.4MPa. |
|
|
Dimensions |
1390*1040*2080 (L*W*H) | |
|
PLC |
It can make the frequency conversion continuously variable and set, adjust, display and memorize the technical parameters, operation speed, air inlet speed, spray force and flow during the operation of the complete machine. |
|
|
Hot air cabinet |
Motor power of hot air filter |
1.5KW (explosion-proof) |
|
Filter precision |
0.5μm |
|
|
Filter cleanliness |
100,000 class |
|
|
Air inlet speed |
2356m³/h (with a class-3 filter) |
|
|
Hot air temperature |
40~80℃ (adjustable) |
|
|
Dimensions |
930*750*2080 (L*W*H) |
|
|
Weight |
350Kg |
|
|
Dust removal cabinet |
Motor power dust removal fan |
3KW (explosion-proof) |
|
Air outlet speed |
5268 m3/h |
|
|
Surface material |
Matt stainless steel |
|
|
Dimensions |
830*830*1850 (L*W*H) |
|
|
Weight |
350Kg |
|
|
Spray gun |
Imported spray gun with uniform atomization, adjustable spray shape, position and angle |
|
|
Motor power of peristaltic pump |
0.25KW |
|
|
Peristaltic pump speed |
100-700 r/min |
|
|
Mainframe weight |
750Kg |
|
